How to Teach Your LLM to Write C4 Diagrams

by Guillermo Quiros

Why we should stop treating software architecture as a paragraph-only problem, and how a skill + MCP approach lets Claude, Codex, and OpenClaw create diagrams in Uxxu as part of their workflow.

New to the model itself? Start with the C4 model hub, then come back here when you are ready to teach an LLM how to use C4 inside Uxxu.

The Strange Habit We All Picked Up

One thing I keep coming back to is how unnatural our interaction with LLMs still is.

We open Claude Code, Codex, Cursor, OpenClaw, or whatever AI coworker we use, and then we start typing paragraphs. We explain the architecture in prose. We describe the actors. We list the services. We explain the dependencies. We add caveats. We paste file paths. We hope the model reconstructs the system in its head well enough to be useful.

That is strange, because software teams do not normally think that way.

For more than twenty-five years, the dominant medium for architecture conversations has been the same:

• boxes
• arrows
• labels
• a shared whiteboard

Developers naturally explain systems visually. Product people do it too. Architects do it. Staff engineers do it. If you walk into a system design meeting, nobody starts by writing five paragraphs of narrative architecture prose. Somebody grabs a marker and draws the first box.

The question is simple:

If diagrams are already our native architecture language, why are we still teaching our LLMs architecture only through prose?

Why C4 Is the Right Language for LLMs

UML tried to solve software modeling as a universal language, and it was impressive. It was also too heavyweight for most everyday engineering work. Teams used it selectively, usually when they had to formalize a point, not when they wanted to think quickly and communicate clearly.

The reason the C4 model stuck is that it matches how teams already reason about systems:

• System Context to understand the boundary
• Container to understand the major building blocks
• Component to understand internal decomposition
• Deployment to understand where things run

That hierarchy matters for humans, and it matters even more for LLMs.

If you hand an LLM a good Context diagram, it immediately understands:

• what the system is
• who uses it
• what is external
• what the important dependencies are

If you hand it a Container diagram, it understands:

• which applications and services exist
• which databases, brokers, and caches matter
• where the synchronous and asynchronous boundaries are

If you hand it a Component diagram, it understands the internal shape of a service without needing you to narrate every module and responsibility from scratch.

That is the key shift:

You are not describing the architecture to the model.
You are showing it the architecture at the correct level of abstraction.

The Real Problem: Models Need More Than a Diagram Viewer

To make this practical, the model needs two different things.

It needs help thinking about architecture, and it needs help acting on architecture.

These are not the same problem.

1. The Skill Teaches the Model How to Think

A skill is where we teach the model the rules of the game:

• how to identify the target C4 level
• how to distinguish actors, systems, applications, and stores
• how to choose the right scope for a Context vs Container vs Component diagram
• how to write high-signal relationships instead of noisy arrows
• how to reuse existing project context before creating new diagrams

In our case, that logic lives in the Uxxu skill:

• skills/uxxu-mcp-diagrams/SKILL.md

The skill teaches a workflow like this:

1. list or identify the target project
2. read the project context
3. optionally read the current diagram or object model
4. create the new C4 diagram

It also teaches the modeling rules:

• use ACTOR for people
• use SYSTEM for software systems in Context diagrams
• use APPLICATION for apps, APIs, gateways, workers, and services in Container diagrams
• use STORE for databases, caches, and search indexes
• add short relationship notes like Calls API, Reads and writes, or Publishes events

This matters because an MCP server alone cannot teach architectural judgment. It can expose tools, but it cannot by itself explain why a passenger should connect to the mobile application rather than directly to the orders database.

2. The MCP Lets the Model Act

The MCP is the execution layer.

In our case, that is:

• uxxu-mcp

The MCP gives the model tools to:

• list projects
• read project context
• read existing diagrams
• create C4 diagrams
• layout the diagram automatically
• choose connectors automatically
• match technologies against the Uxxu technology catalog

The main tool is:

• uxxu_create_c4_diagram

That means the architecture flow becomes two-way:

• Human to model: show the system through C4 context
• Model to Uxxu: create or update diagrams through the MCP

This is much better than a model merely describing changes in text.

Instead of saying:

I added a notification service that subscribes to order events

the model can create the actual diagram that shows:

• the notification service
• the message broker
• the event relationship
• the new technology choices

That is a fundamentally better feedback loop.

The Core Pattern: Skill for Reasoning, MCP for Execution

This is the structure I recommend:

The skill should teach:

• when to use each C4 level
• how to classify elements
• how to interpret architecture prose
• how to name elements and relationships consistently
• how to avoid diagram noise
• how to inspect context before making changes

The MCP should handle:

• reading project and diagram context
• creating diagrams in Uxxu
• auto-layout
• connector selection
• technology matching
• returning a viewerUrl so the result can be opened immediately

This separation is important because it makes the whole setup more robust.

If you change the model, the MCP still works.
If you change the client, the MCP still works.
If you improve the skill, every supported client gets better architecture behavior.

Why Uxxu Is a Good Demo for This

Uxxu is a good demonstration of this approach because it is not just a passive diagram canvas.

It supports both directions:

1. Export structured architecture context for an LLM
2. Accept diagram creation and updates back through MCP

That means the diagram stops being a dead artifact.

It becomes a language between the human and the model.

In practice, the flow looks like this:

1. Create or select a project in Uxxu
2. Export project or diagram context as an LLM prompt when you want the model to understand the current architecture
3. Give the model a change request or a greenfield specification
4. Let the model call the Uxxu MCP
5. Review the created diagram in Uxxu

That is the important shift:

The model is no longer guessing architecture from scattered prose.
It is working with a structured architecture model and writing back into the same system.

What the Recommended Tool Sequence Looks Like

When the model is creating a new diagram from a natural-language description, the best tool sequence is:

1. uxxu_list_projects
2. uxxu_get_project_context
3. optionally uxxu_get_diagram
4. uxxu_create_c4_diagram

That sequence does two useful things:

• it prevents the model from drawing into the wrong project
• it gives the model enough context to reuse existing systems, containers, and relationships when appropriate

This is exactly the kind of behavior that makes an LLM feel less like a guessing engine and more like a competent teammate.

A Simple Skill Prompting Pattern

The easiest way to think about the skill is that it teaches the model a repeatable architecture checklist.

For example:

When asked to create a C4 diagram:

1. Identify whether the user wants a System Context, Container, or Component view.
2. Extract actors, systems, applications, stores, and major relationships.
3. Read existing Uxxu project context before creating anything.
4. Prefer a small number of high-signal relationships.
5. Use technology labels whenever the prompt provides them.
6. Create the diagram through uxxu_create_c4_diagram.
7. Return the viewer URL and state any major assumptions.

That sounds simple, but it is exactly the sort of behavioral scaffolding that turns a raw model into a reliable architecture collaborator.

Installing the Uxxu MCP

The easiest install path is:

npm install -g uxxu-mcp

or:

npx -y uxxu-mcp

Set your API key:

export UXXU_API_KEY=YOUR_API_KEY

The MCP defaults to:

https://app.uxxu.io

So in the normal case you do not need to configure a custom API URL at all.

Using It with Claude Code, Codex, and OpenClaw

Claude Code

Claude Code works well with a local stdio MCP server.

You can register it directly:

claude mcp add --transport stdio uxxu --scope local \
  --env UXXU_API_URL=https://app.uxxu.io \
  --env UXXU_API_KEY=YOUR_API_KEY \
  -- uxxu-mcp

Or, if you are working inside the repository, you can use a project-scoped .mcp.json.

Codex

Register the MCP under the server name uxxu and let the model call:

• uxxu_list_projects
• uxxu_get_project_context
• uxxu_create_c4_diagram

The key thing with Codex is to also install the skill, so the model understands the preferred C4 workflow instead of treating the MCP as a bag of unrelated tools.

OpenClaw

OpenClaw is a particularly nice fit because it supports both MCP registration and a skill installation flow.

The easy path is:

npm install -g uxxu-mcp
export UXXU_API_KEY=YOUR_API_KEY
uxxu-install-openclaw

That installer can:

• register the uxxu MCP server
• install the bundled uxxu-mcp-diagrams skill

For a lot of teams, that is the first truly smooth “teach the model, then let it draw” workflow.

What a Good Prompt Looks Like

Here is a simple example:

Use the uxxu MCP.
Inspect my project context first.
Then create a C4 container diagram for an e-commerce platform with:
- a web application
- iOS and Android mobile apps
- an API gateway
- order, payment, customer, and product services
- PostgreSQL databases
- Kafka
- Stripe
- Auth0
- SendGrid

Return the viewer URL and tell me any assumptions you made.

Notice what this prompt does not need to say:

• how to classify actors
• how to classify stores
• how to choose diagram scope
• how to arrange the layout
• how to choose connectors

That knowledge belongs in the skill and MCP, not in every prompt.

A Real Uxxu Example

Here is a real diagram created through the Uxxu MCP from architecture prose rather than hand-drawn manually:

That is the point of the whole system.

The model receives:

• architecture intent
• project context
• modeling rules

and Uxxu handles:

• diagram creation
• layout
• technology matching
• rendering

The Bigger Idea

The whiteboard never went away because diagrams are not decoration. They are how software people think.

IDEs did not replace diagrams.
Issue trackers did not replace diagrams.
Wiki pages did not replace diagrams.

So it should not surprise us that LLM workflows still feel incomplete when they are diagram-blind.

If the clearest way to explain architecture to a new engineer is a good C4 diagram, then the clearest way to explain architecture to an AI coworker is probably the same.

And if the AI coworker is going to participate meaningfully in design, then it should not only read diagrams. It should also be able to write them back.

That is why I think the right architecture for AI-assisted software design is:

• C4 as the modeling language
• skills as the reasoning layer
• MCP as the execution layer
• Uxxu as the place where the architecture stays visible, editable, and shared

The Practical Payoff

Once this is working well, the benefits are immediate:

• better prompts because the model starts from structured architecture context
• better change planning because the model reasons at the right abstraction level
• better review because the model can show the proposed architecture, not only describe it
• better onboarding because new engineers and LLMs consume the same architecture language

That is the direction I believe software teams should move toward.

Not more prose.

Not larger prompts.

Better shared structure.

And for architecture work, that structure is the diagram.

Frequently Asked Questions

Does the MCP replace the skill?

No. The MCP gives the model tools. The skill teaches the model how to use those tools well. You want both.

Why not just ask the LLM in plain English every time?

Because plain-English prompts force you to restate architecture context repeatedly. A diagram-backed workflow gives the model a much more stable, structured mental model of the system.

Why use C4 instead of UML for this?

C4 is easier to teach, easier to read, and much better suited to everyday software architecture communication. That makes it a better language for AI coworkers too.

Why use Uxxu as the demo?

Because Uxxu supports both sides of the loop: exporting architecture context for the model and accepting diagram creation back through the MCP. That makes it a practical environment for human-model architectural collaboration rather than just a static drawing tool.
